| Model and Ratings | ||||
| Model | Voltage（V） | Current（A） | Ripple (mV) | Av. Eff. (%)Min |
| UES24WZ-120YYYSPA | 12.0 | 0.01-2.00 | 120 | 86.8 |
| YYY:stand for current 0.01-2.00A | ||||
| Others | ||||
| Input Voltage Range | 90-264VAC | |||
| Input Current | 0.8A | |||
| Standby Power | 0.075W MAX | |||
| Output Voltage Tolerance | ±5% | |||
| Safety Standard | CE(EN62368-1), cULus(UL62368-1), CB(IEC62368-1), PSE(J62368-1), RCM(AS/NZS62368.1), FCC(Part 15), EAC(ICE62368-1), | |||
| Environmental | ||||
| Operating Temperature | 0~45℃ | |||
| Storage Temperature | -20~70℃ | |||
| Operating Humidy | 5% to 95% non condensing | |||
| General | ||||
| Weigh | 120g | |||
| Dimensions | 85(L) 51(W) 28(H)mm | |||
| MTBF | 100,000 hours at full load at 25℃ ambient, calculated per MIL-HDBK-217 | |||
